I-STAP-IFX-FLAT

Envision Inlay

A flat, versatile passive inlay designed for core ring wearables, perfect for rings requiring the inlay to sit on the outer surface before sealing. At just 2mm thick, it enables the creation of slender, elegant rings while maintaining outstanding NFC performance. The inlay is MasterCard-certified for the payments industry with flexibility to support additional NFC and Mifare 1k applications. Built on the Infineon SLJ37 Secora Pay platform, it ensures high cryptography and security while opening new use cases such as EMV payments, loyalty programs, access control, events, and hospitality.

Contact Us for price
  • Part number

    I-STAP-IFX-FLAT
  • Dimensions

    from: 2mm x ⌀53.15mm to: 2mm x ⌀83.11mm
  • Max Thickness

    0.72mm
  • Weight

    0.08g
  • Operating Temperature

    -20℃ to +80℃
  • Storage Temperature

    23℃ to ±3℃
  • Storage Duration

    12 months from delivery date
  • Interface

    ISO14443
  • Environmental Compliance

    RoHS, China RoHS
  • Mastercard Certification

    CLOA- DIGI230901- 231027(a)
  • Frequency

    13.56 MHz

Envision ring copy

88.46 KB
